Features
- The Formula to a good ration starts with the basics. Precisely engineered tank walls, baffles and screws provide accuracy and consistency that you expect!
- Precisely Engineered Augers - propel your ration up the center of the auger and then down along the outside walls for fast processing while maximizing end-to-end movement between the 2 screws.
- Lead Edge Scraper is adjustable and replaceable, it is responsible for initiating efficient feed movement in the Formula Mixer (Heat treated - high carbon steel).
- Auger Discharge Kicker Arm (right side of graphic) provides an extra sweep with every revolution, allowing smoother feedout in less time!
- Unique 3 piece knife design saves you time and money! This system offers added strength, simple adjustability and reduced replacement costs. (tungsten carbinate coated knives)
- Perfect Match
Meyer offers a standard 2 blade knife for typical rations or an aggressive 3 section knife for rations with high volumes of long stem material. - Step Baffle System
This unique Step Baffle System aids in front/rear feed movement, reduces horsepower requirements while eliminating overprocessing! Made from High Carbon Steel to reduce wear! NOTICE THE 4" STEP WHERE THE BAFFLE MEETS THE FLOOR. - Simple Direct Drive System
This simple system allows direct driveline hookup from your truck transmission PTO saving you time and expense. Our standard system includes Electric 2-Speed shifting! - Joystick Control
This convenient control center provides effortless control of all critical functions! - Electro-Hydraulic Door Control
This simple electro-hydraulic system provides a simple, efficient means of powering the mixer doors and slide tray (if equipped). - Electric 2-Speed Shifting
Electric 2-Speed shifting standard. Meyer Formula mid-sized mixers operate at 27 RPM in Low Range & 40 RPM in High Range. You can expect efficient mixing, reduced stress on your truck PTO and faster cleanouts with this simple system! - Fully Lubed Planetaries
Meyer Formula Planetaries are sized large to handle heavy loads! These high quality planetaries are full-filled with oil so the upper bearings are bathed in oil - same as the lower. This avoids the added maintenance of greasing upper planetary bearings like many other brands. Oil levels are monitored using these reserviors. - Hay Stops
Hay Stops are double acting and easily adjust for tuning when processing long stemmed material. Most other hay stops only adjust 1 direction (top or bottom - Meyer does both). 2 Stops are standard equipment. - Belt Capacity Extension
8" Belt Capacity Extension packages are available for all Formula Mixers. They generally add about 10% to the mixer capacity (Optional). - Hay Retention Ring
Meyer offers a optional hay retention package. This package is useful when high volumes of long stem material are in your batch. Itkeeps hay from boiling over the tank and maintains good contact between the bale and auger knives. - Stainless Steel Side & Baffle Liners are available as an option for high usage applications.
- Stainless Lined, High Wear Augers
These Stainless-lined, high wear augers are optional on frame twin screw Formula Models. They will extend the life of your mixer screws well beyond the other industry offerings. A 5/8" stainless lead-edge rod preserves the edge of the auger flight while a 4" wide stainless liner protects the upper surface and knife bolt heads - DELUXE! No worries of chipping off chunks of hardfacing like many other high wear choices..... - Meyer offers a wide variety of scalehead options from Digi-Star and Avery Weightronics. Weigh bars and junction box come standard with all Formula mixers.
- Door Options
F585 & F700 Truck Mount mixers are available with a LH side door and an optional rear Commodity Door. Check out the size of these openings - big door opening combined with faster auger speed provide faster discharge and cleanout! - Poly Lined Door Tracks
All Door Tracks are poly lined for reduced wear and stress. They also eliminate freeze up issues and provide easy long term replacement! - Side Door Option #1: 12
Simple 12" Belt Slide Chute works well to deflect feed beyond the truck mixer tire and it's simple - no moving parts! - Side Door Option #2: Hydraulic Folding Slide Tray
This Hydraulic Folding Slide Tray with magnets operates at a steep angle for complete discharge! - Optional Rear Commodity Door
Check out this handy feature for fast discharge of a premix, processed roughage or bedding! - Work Lights
Meyer offers a bunk light package which includes work lights over the discharge and rear bumper area. - Fender Packages Available
Optional Deluxe Poly Fender / Flap kit - Tank Magnet System
This "Super Strength Tank Magnet" hinges open from the outside of the mixer for easy upkeep and cleaning. It's an investment that will pay you back many times over. Other magnet options include - Kick Arm Magnet, Door Frame Magnets & Slide Tray Magnets. - Kicker Arm Magnet
This exciting new magnet outperforms most all other choices and it's priced right. This Rare Earth, round magnet mounts behind our standard kicker arm and collects tramp metal as it circulates through the ration. It provides the perfect hiding spot for iron until you clean it off! If you want a magnet that works at a reasonable price, BUY THIS ONE!
Specs
